Orbitalum GF 4 120V US AVM Pipe & Tube Saw

GF 4 AVM

The GF series Orbitalum GF4 120V US AVM Automatic Feed Module pipe saw sets a new standard in orbital pipe machining. Numerous innovative functions combined with an ergonomic design, create significant advantages for you in the industrial prefabrication of pipeline systems. The GF4 allows cutting of high-alloy steel (stainless steel), low and unalloyed steel, plastics, casting materials and non-ferrous metals in just seconds, using the orbital cutting method.

Automatic Feed Module AVM:
Continuously controls cutting speed using torque and parameter settings, improving handling of GF machines. Stops automatically after the cutting process.

  • Anthracite coated components for improved sliding properties and protection against corrosion
  • Stainless steel clamping attachments (Code 790 142 241) for protection against contact corrosion included
  • Reduce operator fatique with the AVM automatic cutting process feed module
  • Locking security mechanism prevents unauthorized usage and theft
  • All new ergonomically-designed motor handle for a safer, more comfortable operating position, which also enables easy cutting of elbow joints
  • Integrated laser-precision line for determining the cut off point
  • 2 position clamping jaws reduce chatter and enable machining of shorter lengths of pipe
  • Multifunctional tool included for all adjustments on the machine
  • Extended speed range (65 - 215 rpm), ideal for the cutting of high-performance materials (Hastelloy, P91, etc.)
  • Swivel cable with a quick-disconnect coupler for quick, easy power cable replacement
  • New chip guard protects against flying chips and comes with a measuring port
  • The automatic feed module AVM and line laser are already mounted at the GF 4 AVM at delivery.

Includes:

  • GF4 120V US AVM Automatic Feed Module pipe saw
  • Transportation case
  • Set of stainless steel clamping attachments
  • Saw blade (Code 790 042 064)
  • Mounting plate
  • Line laser with fastening screw****
  • Tool set
  • Saw blade lubricant GF TOP (Code 790 060 228)
  • Special gear oil (Code 790 041 030)
  • Operating instructions and spare parts list
